Topaz

General Description

“Washmetic” Tankwasher Topaz‐50, 75 & 100 are ideally suitable for low flow and low pressure
application. Topaz operate from pressure 0.5 bar with flow rate as low as 15 lpm. The range of
Topaz offers a choice to buyer’s for meeting the customized requirements in respect of flow and
pressure

Applications

Topaz Washer’s are compact in design, effective in performance and meets all the essential
FDA material requirements. These Tankwashers’ are suitable for pharmaceutical, biotech, food and
beverage industries

Operations

Topaz washers have slotted rotor which revolves on the shaft on liquid cushion. Different spray
angle is possible by changing slot configurations

Maintenance

No maintenance or spares are required for these washers

Category:

Description

SpecificationTopaz 50Topaz 75Topaz 100
Standard Connection : Thread 3/8" BSP ( Female) 1/2" BSP ( Female) 1.1/4" BSP ( Female)
Optional Connection : Pin Fix1/2" OD pipe, 3/4" OD pipe & 1" OD Pipe Pin Fix 3/8", 1/2" &1.1/4" NPT against Order
Insertion opening Min. Ø 42mm,
Pin Fix Ø 60 mm		Min. Ø 52mm,
Pin Fix Ø 68 mm		Min. Ø 85mm,
Pin Fix Ø 58 mm
Standard Construction Matl. 316L with CPTFE or PTFE
Cleaning diameter in m Max 2.2 meterMax 3.3 meterMax 4.8 meter
Flow Rate in LPM 15 - 33 l/min30 - 76.7 l/min50 - 118.3 l/min
Operating Pressure (in bar)1 - 4 bar 1 - 4 bar 1 - 4 bar
Max. Ambient Temperature Max. 75° C
Max. Operating Temperature Max. 65° C Max. 95° C
Spray angle360°
Preferred mounting Position Any
Weight 0.11 Kg0.16 Kg0.195 Kg
