ChemiTopaz

General Description

“Washmetic” Tankwasher Chemi Topaz‐50,75 & 100 are ideally suitable for low flow and low pressure
applications.Chemi Topaz operate from pressure 0.5 bar with flow rate as low as 15 lpm. The
range of Chemi Topaz offers a choice to buyer’s for meeting the customized requirements in respect of
flow and pressure. Ideally suitable for applications where the wash fluid is likely to be reactive to
stainless steel.

Applications

Chemi Topaz Washer’s are compact in design, effective in performance and meets all the
essential FDA material requirements. These Tankwashers are suitable for pharmaceutical, nuclear,
biotech, food & beverage industries and lots of other applications

Operations

ChemiTopaz washers have slotted rotor which revolves on the shaft on liquid cushion. Different
spray angles are possible by changing slot configurations

Maintenance

No maintenance or spares are required for these washers

Category:

Description

SpecificationChemiTopaz 50ChemiTopaz 75
Standard Connection : Thread 3/8" BSP ( Female) 1/2"BSP (Female)
Optional Connection 1/2" OD Pipe, 3/4" OD Pipe Pin Fix and 3/8" , '1/2" NPT (Female) on order
Insertion opening Min. 0 42 mm Min. 0 52 mm
Standard Construction Matl. CPTFE or PTFE
Cleaning diameter in m Max. 2.2 m Max. 3.3 m
Flow Rate in LPM 15 - 33 1/min30 - 77 1/min
Operating Pressure (in bar)1 - 4 bar 1 - 4 bar
Max. Ambient Temperature Max. 65° C
Max. Operating Temperature Max. 75° C
Spray angle360°
Preferred mounting Position Any
Weight 0.039 Kg0.061 Kg
